TPD1E10B09DPYR Single-channel ESD Transient Voltage Suppressor (TVS) Diode In A Small 0402 Package Key Features
- Provides system-level ESD protection for I/O interfaces up to ±9 V
- IEC 61000-4-2 Level 4:
- ±20 kV (air-gap discharge)
- ±20 kV (contact discharge)
- IEC 61000-4-5 surge protection:
- I/O capacitance of 10 pF (typical)
- R_DYN of 0.5 Ω (typical)
- DC breakdown voltage of ±9.5 V (minimum)
- Ultra-low leakage current of 100 nA (maximum)
- Clamping voltage of 13 V (maximum at |I_PP = 1 A)
- Industrial temperature range: -40°C to 125°C
- Space-saving 0402 form factor (1 mmx0.6 mmx0.5 mm)
TPD1E10B09 DPY(X1SON,2) 1mm * 0.6mm
Applications
- End devices:
- Tablets
- Remote controllers
- Wearables
- Set-top boxes
- Electronic point-of-sale (EPOS)
- E-book readers
- Interfaces:
- Audio lines
- Buttons
- General-purpose input/output (GPIO)
